24-bit 96kHz AD/DA with 32-bit Internal Resolution
ASIO 2.0, GSI/F, and WDM driver supported software, you can transfer digital audiodata at maximum 32-bit internal resolution. It allows for a much greater dynamic range when you working with digital audio.
2-In/2-Out Balaced or Unbalanced Analog Audio Inputs and Outputs
The Waveterminal 2496 provides 1/4" TRS phone jacks for use with either professonal +4dBu nominal level audio equipment or -10dBV nominal level consumer audio equipment.
4 Channel Recording and Playback
You can record analog and digital sources simultaneously and play them back simultaneously as well.
24-bit 96kHz S/PDIF Coxial Digital In & Out
Unlike some audio cards that claim 24-bit 96kHz capability, the Waveterminal 2496 offers a true 24-bit 96kHz S/PDIF digital input and output.
Multiple Sample Rate Support
The Waveterminal 2496 supports all denominations of 44.1kHz or 48kHz standard sample rates from 8kHz to 96kHz(8kHz, 11.025kHz, 12kHz, 16kHz, 22.05kHz, 24kHz, 32kHz, 44.1kHz, 48kHz, 64kHz, 88.2kHz, and 96kHz).
Specifications.
- 24-Bit/96kHz A/D converter; 100dB Dynamic range and 64 x oversampling
- 24-Bit/96kHz D/A converter; 110dB Dynamic range and 128 x oversampling
- Signal-to-Noise Ratio (D/A) ; 110dB
- Analog 2 In / 2 Out ; +4 dBu/-10dBV Bal/Unbal 1/4" TRS phone jack
- 4-Channel Recording/Playback (2 Analog / 2 Digital ) at the same time
- 24-Bit 96kHz S/PDIF Digital I/O (Coaxial)
- Supports multiple Sample Rates:
- 8kHz, 11.025kHz, 12kHz, 16kHz, 22.05kHz, 24kHz, 32kHz, 44.1kHz, 48kHz, 64kHz, 88.2kHz ,96kHz
- Uses 32-Bit PCI slot; PCI bus-mastering support
- Real-time hardware sample-rate converting
- CD-Rom Digital input
- Digital connector for Sound Blaster series (SB-Link )
- Internal Word Clock Connector
- Supports the E-WDM driver
- Multiple MME, Multiple Direct sound,
- ASIO 2.0 and GigaStudio
- OS: Microsoft Windows XP/2000/ME/98SE
- Windows 95/98 driver also provided
- Supports MAC OS8, but MAC OS9 is not supported
- Optional 2X2 MIDI Interface Miditerminal 2120 (sold seperately)
